Chapter 7 Fastening Instructions
PAGE 7-16
<Three-step Fastening – Using 1
st
and 2
nd
Angle (synchronize/stops)>
<Three-step Fastening – Using 1
st
Angle and 2
nd
Torque (synchronize/stops)>
・
・・
・Set 1
st
Torque equal to Full Scale Torque and 2
nd
Angle higher than the Final Angle
High Limit.
・
・・
・Set 1
st
Torque and 2
nd
Torque Equal to Full Scale Torque.
Torque
Angle/Time
1
st
Time
2
nd
Time
Standard Angle
Ramp Down Start Torque
1
st
Angle
2
nd
Torque
Torque
Angle/Time
1
st
Time
2
nd
Time
Standard Angle
Ramp Down Start Torque
1
st
Angle
2
nd
Angle
Snug Torque
Snug Torque
