FEC AFC3000 - 8-4-2 Parameter Selection Mode

Chapter 8 System Operation
PAGE 8- 19
8-4-2 Parameter Selection Mode
Immediately after “Parameter Selection Mode” is established, the cursor (blinking number) is displayed on the
PAR No. Display when the [◄] push-button is pressed. When the [►] push-button is pressed, the cursor
(blinking number) is displayed on the D-No. Display.
The display set value of the cursor (blinking character) can be changed by ±1 using the [▲] or [▼]
push-button. The numbers can be advanced 10 at a time by holding the [▲] or [▼] push-button longer.
“Parameter Edit Mode” can be entered by pressing the [ ◎ SET] push-button.
Parameter Edit Mode
(PAGE 8-18)
►
◄
▲ ▼
◎ SET
◎ SET
◎ SET
►
◄
(By pressing the [►]
or [◄] pushbuttons,
you can quickly
change modes – in
this example
System Parameter
to Parameter
Select)
