8-7-1 Parameter Lists
＜
＜＜
＜System Parameters＞
＞＞
＞ PAR No. display: “SYS”
Item D-No. Contents Units
Controller
Information 1
000
Torque Unit
001 Software Version
<* Cannot be changed.>
002 Amplifier Version
<* Cannot be changed.>
003 System Indication (Multi or Single)
004 External Gear Ratio
005 For in-house adjustment
<* Cannot be changed.>
006 For in-house adjustment
<* Cannot be changed.>
007 Communication Axis Indication (Master or Slave)
008 Controller Cycle Count (×1 million)
009 Controller Cycle Count (×1)
010 Controller maximum current
011 IP Address (upper 6 digits): 192.168
012 IP Address (lower 6 digits): 11.10
013 Subnet Mask (upper 6 digits): 255.255
014
Subnet Mask (lower 6 digits): 128.0
015
Default Gateway (upper 6 digits): 192.168
016 Default Gateway (lower 6 digits): 11.1
017
MAC Address (upper 6 digits): 001F98<* Cannot be changed.>
018
MAC Address (lower 6 digits): 001000<* Cannot be changed.>
019 RTC: Year/Month/Day “130725” July 25, 2013
020
RTC: Time “123456” 12:34 56
021
Erase Fastening Result History/Format CF Card
022 Parameter Copy
023 For in-house adjustment
<* Cannot be changed.>
024 FPGA version of the controller
<* Cannot be changed.>
025 FPGA version of MFC-CF module <*Cannot be changed.>
Connected Tool
Settings
<* Cannot be
changed.>
100 Connected Tool No.
101 Connected Tool Information “201RS1”
102 Tool CAL Torque Decimal Point Position
103 Tool CAL Torque Nm
104 Tool CAL Voltage V
105 Tool ZERO Voltage V
106 Tool Internal Gear Ratio (×100)
107 Tool Serial No. (upper 3 digits)
108 Tool Serial No. (lower 4 digits)
109 Tool Rotation Direction
110 Tool Order No. (upper 2 digits)
111
Tool Order No. (lower 5 digits)
112 Tool Cycle Count (×1 million)
113
Tool Cycle Count (×1)
