Chapter 8 System Operation
PAGE 8- 29
Item
D-No. Contents Units
Controller
Information
2
200
Controller Setting Tool No.
201 Controller Setting Tool Information (ex. “201RS1”)
202 Parameter Setting File Version
203 Sequence Setting File Version
204 PLC Output Layout Setting File Version
205 Fieldbus Setting File Version
206 Fieldbus Message Setting File Version
207 RS232C Input/Output Setting File Version
208
Unit RS232C Communication Speed<* Cannot be changed.>
bps
209
Controller RS232C Parity <* Cannot be changed.>
210
Controller RS232C Stop Bit <* Cannot be changed.>
bit
211
Controller RS232C Data Bit <* Cannot be changed.>
bit
Expansion
Unit 1
(Fieldbus)
Information
<* Cannot
be
changed.>
300
Connected Fieldbus Information
301
ANYBUS interface card Version
302
Controller Setting Fieldbus Information
303
Station No. (Node Address) (1 to 64 or 0 to 63)
304
Communication Speed (0 to 4)
305
Occupied Stations (1, 2, 3, 4)
306
Extended Cyclic Setting (1, 2, 4, 8)
307
I/O Setting Byte Length “PLC → MASTER Axis”
308
I/O Setting Byte Length “Master Axis → PLC”
309
Message Block Byte Length
310
Message Setting Byte Length “PLC → MASTER Axis”
311
Message Setting Byte Length “Master Axis → PLC”
312
IP Address (upper 6 digits)
313
IP Address (lower 6 digits)
314
Subnet Mask (upper 6 digits)
315
Subnet Mask (lower 6 digits)
316
Gateway (upper 6 digits)
317
Gateway (lower 6 digits)
Expansion
Unit 2
Information
<* Cannot
be
changed.>
400
CF Card Storage Capacity
%
401
Expansion RS232C-2 Communication Speed
bps
402
Expansion RS232C-2 Parity
403
Expansion RS232C-2 Stop Bit
bit
404
Expansion RS232C-2 Data Bit
bit
405
Expansion RS232C-3 Communication Speed
bps
406
Expansion RS232C-3 Parity
407
Expansion RS232C-3 Stop Bit
bit
408
Expansion RS232C-3 Data Bit
bit
