Chapter 8 System Operation
PAGE 8- 47
8-7-6 Fastening Parameters (Rate / Time)
D-No.300 1
ST
Rate Low Limit [Nm/deg]
Setting Range ： Tool’s minimum torque rate ～ tool’s maximum torque rate
Set the low limit for the slope of torque and angle measured between two points from D-No.112 [1
ST
Rate
Start Torque] to D-No.113 [1
ST
Rate End Torque].
Judgment is conducted at the point when the D-No.113 [1
ST
Rate End Torque] is reached.
D-No.301 1
ST
Rate High Limit [Nm/deg]
Setting Range ： Tool’s minimum torque rate ～ tool’s maximum torque rate
Set the high limit for the slope of torque and angle measured between two points from D-No.112 [1
ST
Rate Start Torque] to D-No.113 [1
ST
Rate End Torque].
Judgment is conducted at the point when the D-No.113 [1
ST
Rate End Torque] is reached.
D-No.302 2
ND
Rate Low Limit [Nm/deg]
Setting Range: Tool’s minimum torque rate ～ tool’s maximum torque rate
Set the low limit for the slope of torque and angle measured between two points from D-No.114 [2
ND
Rate
Start Torque] to D-No.115 [2
ND
Rate End Torque].
Judgment is conducted at the point when the D-No.115 [2
ND
Rate End Torque] is reached.
D-No.303 2
ND
Rate High Limit [Nm/deg]
Setting Range ： Tool’s minimum torque rate ～ tool’s maximum torque rate
Set the high limit for the slope of torque and angle measured between two points from D-No.114 [2
ND
Rate Start Torque] to D-No.115 [2
ND
Rate End Torque].
Judgment is conducted at the point when the D-No.115 [2
ND
Rate End Torque] is reached.
D-No.304 3
RD
Rate Low Limit [Nm/deg]
Setting Range ： Tool’s minimum torque rate ～ tool’s maximum torque rate
Set the low limit for the slope of torque and angle measured between two points from D-No.116 [3
RD
Rate
Start Torque] to D-No.117 [3
RD
Rate End Torque].
Judgment is conducted at the point when the D-No.117 [3
RD
Rate End Torque] is reached.
D-No.305 3
RD
Rate High Limit [Nm/deg]
Setting Range ： Tool’s minimum torque rate ～ tool’s maximum torque rate
Set the high limit for the slope of torque and angle measured between two points from D-No.116 [3
RD
Rate Start Torque] to D-No.117 [3
RD
Rate End Torque].
Judgment is conducted at the point when the D-No.117 [3
RD
Rate End Torque] is reached.
･
･･
･
The minimum (maximum) torque rate of a tool differs according to the tool model.
Please refer to “Tool Models” on Section 2-2-3 regarding the allowed input range.
Caution
