Chapter 3 System Description
PAGE 3-15
3-2-8 Cable Specification
● Single System Wiring Diagram
* Please refer to cabling chart (below wiring diagrams) for details on the respective cables.
Host PC/Server
AFC3000
User
Console
Software
Control Power
Source
24V DC
Noise
Filter
3-phase Power
Source
200 to 230V AC
50/60Hz
* Must be grounded
* CP: Circuit Protector
Noise
Filter
External PLC
Tool Unit 1
(CFT
-
***RS*)
Tool Unit 2
(CFT-***RS*)
I/O Connector
Drive Power
Cable
Axis Link
terminator
Axis Link
terminator
SLAVE Spdl (No. 2)
Single Control
MASTER Spdl (No. 1)
Single Control
Maximum 32-Spdl
configuration
