Chapter 3 System Description
PAGE 3-30
* I/O Expansion Connector Pin Configuration
Pin
no
Wire Color* Details
Pin
no.
Wire Color* Details
1
Orange ･ Black 1
IN COMMON1 35
Orange ･ Red 1
OUT COMMON1
2
Grey ･ Black 1
IN COMMON2 36
Grey ･ Red 1
OUT COMMON2
3 White ･ Black 1 IN DATA1 37 White ･ Red 1 OUT DATA1
4 Yellow ･ Black 1 IN DATA2 38 Yellow ･ Red 1 OUT DATA2
5 Pink ･ Black 1 IN DATA3 39 Pink ･ Red 1 OUT DATA3
6
Orange ･ Black 2
IN DATA4 40
Orange ･ Red 2
OUT DATA4
7
Grey ･ Black 2
IN DATA5 41
Grey ･ Red 2
OUT DATA5
8
White ･ Black 2
IN DATA6 42
White ･ Red 2
OUT DATA6
9
Yellow ･ Black 2
IN DATA7 43
Yellow ･ Red 2
OUT DATA7
10
Pink ･ Black 2
IN DATA8 44
Pink ･ Red 2
OUT DATA8
11 Orange ･ Black 3 IN DATA9 45 Orange ･ Red 3 OUT DATA9
12 Grey ･ Black 3 IN DATA10 46 Grey ･ Red 3 OUT DATA10
13 White ･ Black 3 IN DATA11 47 White ･ Red 3 OUT DATA11
14
Yellow ･ Black 3
IN DATA12 48
Yellow ･ Red 3
OUT DATA12
15
Pink ･ Black 3
IN DATA13 49
Pink ･ Red 3
OUT DATA13
16
Orange ･ Black 4
IN DATA14 50
Orange ･ Red 4
OUT DATA14
17
Grey ･ Black 4
IN DATA15 51
Grey ･ Red 4
OUT DATA15
18
White ･ Black 4
IN DATA16 52
White ･ Red 4
OUT DATA16
19 Yellow ･ Black 4 IN DATA17 53 Yellow ･ Red 4 OUT DATA17
20 Pink ･ Black 4 IN DATA18 54 Pink ･ Red 4 OUT DATA18
21 Orange ･ Black continuous IN DATA19 55 Orange ･ Red continuous OUT DATA19
22
Grey ･ Black continuous
IN DATA20 56
Grey ･ Red continuous
OUT DATA20
23
White ･ Black continuous
IN DATA21 57
White ･ Red continuous
OUT DATA21
24
Yellow ･ Black continuous
IN DATA22 58
Yellow ･ Red continuous
OUT DATA22
25
Pink ･ Black continuous
IN DATA23 59
Pink ･ Red continuous
OUT DATA23
26
Orange ･ Long black 1
IN DATA24 60
Orange ･ Long Red 1
OUT DATA24
27 Grey ･ Long black 1 IN DATA25 61 Grey ･ Long Red 1 OUT DATA25
28 White ･ Long black 1 IN DATA26 62 White ･ Long Red 1 OUT DATA26
29 Yellow ･ Long black 1 IN DATA27 63 Yellow ･ Long Red 1 OUT DATA27
30
Pink ･ Long black 1
IN DATA28 64
Pink ･ Long Red 1
OUT DATA28
31
Orange ･ Long black 2
IN DATA29 65
Orange ･ Long Red 2
OUT DATA29
32
Grey ･ Long black 2
IN DATA30 66
Grey ･ Long Red 2
OUT DATA30
33
White ･ Long black 2
IN DATA31 67
White ･ Long Red 2
OUT DATA31
34
Yellow ･ Long black 2
IN DATA32 68
Yellow ･ Long Red 2
OUT DATA32
* Example: Orange ･ Black 2
Wire color: Orange Black dots: 2 dots
