Chapter 3 System Description
PAGE 3-29
■ I/O Cable for expansion unit
（
Part #
：
FEB-1643)
* This cable can only be used with Expansion Unit I/O (MFC-DT : 32IN / 32OUT)
● Cable Drawing (dimension units: mm)
● Connector Model No. (Unit Side)
No.
Type
Manufacturer
Model No. Specifications
1 Cable Harness Misumi SD31-HH-A-68-3
length: 3 meter
2 DIN Rail Terminal CZH-Labs MD-D1057DBT-1
*Both items supplied when ordering part #FEB-1643
*Cable color code on following page
To Next Page
