Chapter 4 Installation and Wiring
PAGE 4-10
“L” Version Tool
● CFT-101RS1-SL, CFT-201RS1-SL, CFT-281RS1-SL , CFT-401RS1-SL
(Front mounting dimensions same as standard tool above)
Tool Type
Max.
Torque
[Nm]
Max.
RPM
[rpm]
Min.
RPM
[rpm]
Mass
[kgf]
Square
Drive
[□mm]
Length
L
[mm]
A
[mm]
CFT-101RS1-SL 10 3,000 1 1.3 9.5 266 236
CFT-201RS1-SL 20 1,293 1 1.4 9.5 281 251
CFT-281RS1-SL 28 992 1 1.4 9.5 284 254
CFT-401RS1-SL 40 712 1 1.4 9.5 284 254
