FEC AFC3000 - Page 74

Chapter 4 Installation and Wiring
PAGE 4-11
Standard Tool
● CFT-801RS3-S, CFT-132RS3-S(1)
“L” Version Tool
● CFT-801RS3-SL, CFT-132RS3-S(1)L
(Front mounting dimensions same as standard tool above)
Tool Type
Max. Torque
[Nm]
Max. RPM
[rpm]
Min. RPM
[rpm]
Mass
[kgf]
Square
Drive
[□mm]
CFT-801RS3-S(L) 80 1,015 1 3.4 12.7
CFT-132RS3-S1(L) 130 574 1 3.4 12.7
