UMG70XV3-4EN 12.01.2009 125
13 Storing and Output of Measured Values
Offline Output
During offline output, columns will only be generated if at least one measured value is
stored in the data set. The columns Q_POS and Q_NEG will not be generated if the total-
izers are deactivated.
Transmission Parameters
• the flowmeter sends CRLF-terminated ASCII
• max. line length: 255 digits
• RS232: 9600 bits/s, 8 data bits, even parity, 2 stop bits, protocol (RTS/CTS)
• RS485: 9600 bits/s, 8 data bits, even parity, 1 stop bit
The settings for the RS485 interface can be changed in SPECIAL FUNCTION\SYS-
TEM SETTINGS\NETWORK. These displays will not be indicated if an RS485 interface
does not exist.
13.2.6 Settings of the Serial Output
Some format settings of the serial output can be edited in SPECIAL FUNCTION\SYSTEM
SETTINGS\SERIAL TRANSMIS.
Select SPECIAL FUNCTION\SYSTEM SET-
TINGS\NETWORK to change the settings for the trans-
mission parameters.
Press ENTER to confirm the instrument address in
the network.
Select the the list item DEFAULT to display the default
transmission parameters.
Select SETUP to change the transmission parame-
ters. Press ENTER.
The next display has 3 scroll lists.
• BAUD: baud rate
• PARITY: parity
• ST: number of stop bits
If ON is selected, space characters will not be transmit-
ted. The file size will be considerably reduced (shorter
transmission time).
decimal marker to be used for floating point variables
(point or comma).
character to be used for separating columns (semicolon
or tabulator). This setting depends on the PC program
used.
Serial protocol
default >SETUP<
>BAUD< parity st
1200 EVEN 1
SER:decimalpoint
’.’ >’,’<
SER:col-separat.
’;’ >’TAB’<
