Flexim FLUXUS G704 User Manual

208 UMG70XV3-4EN 12.01.2009
B Menu Structure
B Menu Structure
cold start
resistant
Program Branch PARAMETER
main menu: selection of the program branch
PARAMETER
selection of a measuring channel (A, B) or of
a calculation channel (Y, Z)
This display will not be indicated, if the flow-
meter has only one measuring channel.
When a measuring channel is selected (A, B)
input of the outer pipe diameter
input of the pipe circumference
This display is indicated only, if PIPE CIR-
CUMFER. has been activated in SPECIAL
FUNCTION\SYSTEM SETTINGS\DIALOGS/
MENUS and OUTER DIAMETER = 0 has been
entered.
input of the pipe wall thickness
default: 3 mm
selection of the pipe material
input of the sound velocity of the pipe materi-
al
range: 600...6553.5 m/s
This display is indicated only if OTHER MA-
TERIAL has been selected.
>PAR< mea opt sf
Parameter
Parameter 
for Channel A:
Outer Diameter
100.0 mm
Pipe Circumfer.
314.2 m m
Wall Thickness
3.0 mm
Pipe Material 
Carbon Steel
c-Material
3230.0 m/s
