11 Displaying the Measured Values
The AutoMux mode is the default display mode. It will be activated automatically after a
cold start.
All Channels
The measured values of all channels (measuring and calculation channels) will be dis-
played. The next active channel is selected after min. 1.5 s.
Only Calculation Channels
The measured values of the calculation channels will be displayed only. The next active
calculation channel is selected after min. 1.5 s.
11.2.2 HumanMux Mode
The measured values of one channel will be displayed in HumanMux mode. The mea-
surement on the other channels will be continued, but not displayed:
Press key to display the next activated channel. The measured values of the selected
channel will be displayed as configured in the program branch OUTPUT OPTIONS (see
section 11.1).
11.3 Adjustment of the Display
During measurement, the display can be adjusted as to display two measured values si-
multaneously (one in each line of the display). This does not have influence on totalizing,
storing of measured values, measured value output, etc.
The following information can be displayed in the upper line:
• designation of the physical quantity
• totalizer values, if activated
• temperatures linked to the channel and their difference, if the temperature is measured
• date and time at which the data memory will be full
• measuring mode
• transducer distance
• alarm state indication if activated (see section 18.6.5) and if alarm outputs are activat-
ed
Note! This mode can only be activated if min. two calculation channels are
activated.
The selected channel will be displayed left in the upper
line.
