17 Inputs
17.4 Activation of the Inputs
17.4.1 Activation of Temperature Inputs
Temperature inputs have to be activated if the measured temperatures have to be dis-
played, stored and/or output or if the measured temperature is to be used for the interpo-
lation of viscosity and density of the medium.
17.4.2 Activation of Other Inputs
Inputs have to be activated if the measured values are to be displayed, stored and/or out-
put together with the other measured values.
Note! The configuration of a measuring channel will be stored when the
next channel is selected. The configuration dialog of a channel has to
be finished to store the changes.
Note! The activation of the inputs in program branch OUTPUT OPTIONS will
be displayed only if the flowmeter has inputs of the corresponding
type and they are linked to a measuring channel.
Note! If HEAT FLOW is selected as physical quantity, the corresponding
temperature inputs will be automatically activated. The steps de-
scribed below are only necessary if the measured temperatures are
to be displayed or output.
Select in the program branch OUTPUT OPTIONS the chan-
nel for which a temperature input has to be activated.
The temperature inputs linked to the channel will be dis-
played one after another. Select YES for the temperature
inputs to be activated.
Note! The total number of measured values that can be stored will be re-
duced if a temperature input is activated.
Attention! Observe the polarity to avoid damage of the current source. The cur-
rent input might be destroyed by a permanent short circuit.
Select in the program branch OUTPUT OPTIONS the chan-
nel for which an input has to be activated.
The inputs linked to the channel will be displayed one after
another. Select YES for the inputs to be activated.
Note! The total number of measured values that can be stored will be re-
duced if an input is activated.
