148 UMG70XV3-4EN 12.01.2009
17 Inputs
17 Inputs
External transducers can be connected to the inputs (if available) to measure the follow-
ing physical quantities:
• temperature
•density
• pressure
• kinematic viscosity
• dynamic viscosity
The values of the current, voltage or temperature inputs can be used by all measuring
channels.
An input has to be linked to a measuring channel (see section 17.1 and 17.3) and has to
be activated (see section 17.4) before it can be used for the measurement or for storing
of measured values.
Depending on the configuration of the flowmeter, one or several of the following list items
will be displayed:
17.1 Linking the Temperature Inputs to the Measuring Channels
17.1.1 Linking the Temperature Inputs
Note! If a new input is installed, the flowmeter has to be restarted (RESET)
to identify the new inputs.
Select SPECIAL FUNCTION\SYSTEM SETTINGS\PROC.
INPUTS.
Table 17.1: List items of the scroll list PROC. INPUTS
list item function
LINK TEMPERATURE linking temperature inputs to measuring channels
LINK OTHERS linking other inputs to measuring channels
PT100/PT1000 selection of a temperature probe (FLUXUS G704)
...GO BACK return to the precedent menu item
Select SPECIAL FUNCTION\SYSTEM SETTINGS\PROC.
INPUTS. Press ENTER.
Select the list item LINK TEMPERATURE.
SYSTEM settings
Proc. inputs
SYSTEM settings
Proc. inputs
Proc. inputs
Link temperature
