76 UMG70XV3-4EN 12.01.2009
9 Start-up
9 Start-up
9.1 Switching on
9.2 Displays
9.2.1 Main Menu
The selected program branch is displayed in capital letters between arrows. The com-
plete name of the selected program branch is displayed in the lower line.
Select a program branch with key and . Press ENTER.
As soon as the flowmeter is connected with the power sup-
ply it will be displayed which transducer has been detected
at which channel.
Afterwards the serial number of the flowmeter will be dis-
played for a short time.
Data can not be entered while the serial number is dis-
played.
After initialization, the main menu is displayed in the se-
lected language. The language of the display can be set
(see section 9.4).
The main menu contains the program branches:
• PAR (parameters)
• MEA (measuring)
• OPT (output options)
• SF (special functions)
Note! By pressing key BRK, the measurement will be stopped and the main
menu selected.
Note! In this manual, all program entries and keys are indicated in capital
letters. Program entries are indicated in typewriter characters (PA-
RAMETER). The menu items will be separated from the main menu by
a backslash "\".
FLEXIM FLUXUS
G70X-XXXXXXXX
>PAR< mea opt sf
Parameter
>PAR< mea opt sf
Parameter
