118 UMG70XV3-4EN 12.01.2009
13 Storing and Output of Measured Values
13.1 Data Memory
13.1.1 Activating/Deactivating of the Data Memory
13.1.2 Setting the Storage Rate
The storage rate is the frequency at which the measured values are output or stored. The
storage rate will be set separately for each measuring channel.
If the storage rate is not set, the storage rate previously selected will be used.
The storage interval should be at least equal to the number of activated measuring chan-
nels, e.g. storage interval of a channel if 2 measuring channels are activated: min. 2 s.
13.1.3 Measuring Point Number
At the beginning of the measurement, the measuring point has to be identified, either
• by ASCII text (e.g. MS.PK20!) or
• by digits, including point, hyphen (e.g. 18.05-06).
The input mode will be set in program branch SPECIAL FUNCTION (see section 15.2.3).
Select in the program branch OUTPUT OPTIONS the
channel for which the data memory has to be activated.
Press ENTER.
This display will not be indicated, if the flowmeter has
only one measuring channel.
Press ENTER until the menu item STORE MEAS.DATA
is displayed.
Select YES to activate the data memory. Press ENTER.
Select a storage rate.
This display is indicated only if STORE MEAS.DATA
and/or SERIAL OUTPUT have been activated.
If another storage rate has to be set, select EXTRA.
Press ENTER.
Enter the storage rate. Press ENTER.
Output Options
for Channel A:
Storage Rate
once per 10 sec.
To Next Page
