UMG70XV3-4EN 12.01.2009 157
18 Outputs
18.2 Error Value Delay
The error value delay is the time interval after which the error value will be transmitted to
the output in case no valid measured values are available. The error value delay can be
entered in the program branch OUTPUT OPTIONS if this menu item has been previously
activated in the program branch SPECIAL FUNCTION. If the error value delay is not en-
tered, the damping factor will be used.
18.3 Activation of an Analog Output
18.3.1 Measuring Range of the Analog Outputs
After an analog output has been activated in the program branch OUTPUT OPTIONS, the
measuring range of the source item has to be entered.
Select SPECIAL FUNCTION\SYSTEM SETTINGS\DIA-
LOGS/MENUS\ERROR-VAL. DELAY
Select DAMPING if the damping factor is to be used as er-
ror value delay. Select EDIT to activate the error value de-
lay request.
From now on, the error value delay can be entered in the
program branch OUTPUT OPTIONS.
Note! An output can only be activated in the program branch OUTPUT OP-
TIONS if it has been previously installed.
Select in the program branch OUTPUT OPTIONS the chan-
nel for which an output has to be activated. Press ENTER.
This display will not be indicated, if the flowmeter has only
one measuring channel.
Press ENTER until CURRENT LOOP is displayed. Select
YES to activate the output. Press ENTER.
Select SIGN if the sign of the measured values has to be
considered for the output.
Select ABSOLUT if the sign does not need to be consid-
ered.
Enter in ZERO-SCALE VAL. the lowest measured value
expected. The unit of measurement of the source item will
be displayed.
ZERO-SCALE VAL. is the measured value corresponding
to the lower limit of the output range as defined in section
18.1.1.
Error-val.delay
>DAMPING< edit
Error-val. delay
10 s
Output Options
for Channel A:
Current Loop
I1: no >YES<
Meas.Values
>ABSOLUT< sign
Zero-Scale Val.
0.00 m3/h
