Flexim FLUXUS G704 User Manual

UMG70XV3-4EN 12.01.2009 75
8 Installation of the Temperature Probe (Option)
8.2 Connection of the Temperature Probe
• Connect the temperature probe with the temperature input of the flowmeter.
Tabelle 8.1: Terminal strip KL2 of the flowmeter
terminal connection of
temperature probe
connection of
extension cable
T1a...T4a red red
T1A...T4A red/blue gray
T1b...T4b white/blue blue
T1B...T4B white white
S1...S4 shield shield
