13 Storing and Output of Measured Values
Measuring point number and parameters will be stored together with the measured val-
ues.
13.1.4 Measurement
If no other measured value output is activated, the measurement will be stopped.
If another measured value output is activated, the measurement will be continued. Only
storing of the measured values will be stopped. The error message will be displayed pe-
riodically.
13.2 Output of the Measured Values
The measured values can be output via the serial interface. For the connection of the in-
terface to the flowmeter see section 6.9 (FLUXUS G704), 7.7 (FLUXUS G709).
13.2.1 RS232 Interface
• output of the measured values in ASCII format
• transmission of the stored measured values by means of the program FluxData in bi-
nary format
The cover of the flowmeter has to be opened to output the measured values via the
RS232 interface.
13.2.2 RS485 Interface
• output of the measured values in ASCII format
• transmission of the measured values via a bus protocol (flowmeter as Modbus slave)
If arrows are displayed, ASCII text can be entered.
If digits are displayed, only digits, point and hyphen can
be entered.
Enter the measuring point number. Press ENTER.
If OUTPUT OPTIONS\STORE MEAS.DATA is activated
and SPECIAL FUNCTION\SYSTEM SETTINGS\RING-
BUFFER is deactivated, this error message will be dis-
played as soon as the data memory is full. Press EN-
TER.
Attention! Never open the housing in explosive atmosphere if the flowmeter is
connected with the power supply.
Note! It is recommended to use the RS485 interface for the online output.
The RS232 interface should be used only if the flowmeter does not
have an RS485 interface.
