UMG70XV3-4EN 12.01.2009 141
15 Settings
15.2.2 Medium Pressure
The dependency of the properties of a medium on the pressure can be taken into ac-
count.
This display is indicated only if in SPECIAL FUNCTION\SYSTEM SETTINGS\MEASUR-
ING the GAS MEASURING has been deactivated. If GAS MEASURING is activated, the
medium pressure will always be requested in the program branch PARAMETER.
15.2.3 Measuring Point Number
15.2.4 Transducer Distance
If ON is selected, the medium pressure will be requested in
the program branch PARAMETER.
If OFF is selected, 1 bar will be used for all calculations.
Note! It is reasonable for documentation purpose to enter the medium pres-
sure even if no pressure dependent characteristics are stored in the
flowmeter.
Select 1234 if the measuring point is to be identified only
by numbers, point and dash.
Select if the measuring point is to be identified by
the ASCII editor.
recommended adjustment: USER
• USER will be selected if the measuring point is always
the same.
• AUTO can be selected if the measuring point often
changes.
In the program branch MEASURING, the recommended
transducer distance will be displayed in parentheses, fol-
lowed by the entered transducer distance if the recom-
mended and the entered transducer distance are not iden-
tical.
During transducer positioning in the program branch MEA-
SURING
• only the entered transducer distance will be displayed if
TRANSD. DISTANCE\USER is selected and the recom-
mended and the entered transducer distances are iden-
tical
• only the recommended transducer distance will be dis-
played if TRANSD. DISTANCE\AUTO is selected.
Meas. Point No.:
(1234) >()<
Transd. Distance
auto >USER<
Transd.Distance?
(50.8) 50.0 mm
