UMG70XV3-4EN 12.01.2009 77
9 Start-up
9.2.2 The Program Branches and their Menu Items
• The pipe and medium parameters will be input in the program branch PARAMETER.
• The steps for the measurement will be processed in the program branch MEASURING.
• Physical quantity and unit of measurement as well as all parameters necessary for the
measured value output will be defined in the program branch OUTPUT OPTIONS.
• All functions that are not directly related with the measurement are in program branch
SPECIAL FUNCTION.
For an overview of the program branches see section 9.2.3. For a detailed overview of
the menu structure see annex B.
9.2.3 Overview of the Program Branches
1
The following menu items are in SYSTEM SETTINGS:
• dialogs/menus
• inputs
• measurement
• gas measurement
• outputs
•storing
• serial output
• miscellaneous
• set clock
•libraries
parameter
>PAR<
selection of the
measuring channel
pipe parameters
medium parameters
transducer type
extension cable
measuring
>MEA<
selection of the
measuring channel
measuring
point number
sound path
transducer
positioning
measurement
consistency check
output options
>OPT<
selection of the
measuring channel
physical quantity
unit of measurement
damping
measured value
output
special function
>SF<
system settings
1)
instrument
information
print measured
values
delete measured
values
program code
install material
install medium
