UMG70XV3-4EN 12.01.2009 171
measuring functions
physical quantities operational volume flow, standard volume flow, mass flow,
flow velocity
totalizers volume, mass
calculation functions average, difference, sum
data logger
loggable values all physical quantities and totalized values
capacity > 100 000 measured values
communication
interface - process
integration
:
option:
RS485 (Modbus, emit-
ter)
- diagnosis: RS232
- process
integration
:
option:
RS485 (Modbus, emit-
ter)
- diagnosis: RS232
1
- process
integration
:
option:
RS485 (Modbus, emit-
ter)
- diagnosis: RS232
serial data kit (option)
software (all Win-
dows
TM
versions)
- FluxData: download of measured data, graphical presentation,
conversion to other formats (e.g. for Excel
TM
)
- FluxKoeff: creating medium data sets
cable
RS232 RS232
1
RS232
adapter
RS232 - USB RS232 - USB
1
RS232 - USB
outputs (option)
The outputs are galvanically isolated from the flowmeter.
number on request
current output
range 0/4...20 mA
accuracy 0.1 % of reading ±15 A
active output R
ext
< 500
passive output U
ext
= 4...24 V, dependent on R
ext
, R
ext
< 1 k
voltage output
range 0...1 V or 0...10 V
accuracy 0...1 V: 0.1 % of reading ±1 mV
0...10 V: 0.1 % of reading ±10 mV
internal resistance R
i
= 500
frequency output
range 0...1 kHz or 0...10 kHz
open collector 24 V/4 mA
1
connection of the interface RS232 outside of explosive atmosphere (housing cover open)
FLUXUS G704 G704 A2 G709
