4. In Step 3, if [Middle] or [Top & Bottom] is selected, enter both "#1" (upper limit) and
"#2" (lower limit).
#1: Even numbers from 0 to 508mm can be entered. Odd numbers will be made even by
adding one.
#2: Even numbers from 0 to 510mm can be entered. Odd numbers will be made even by
adding one.
5. Press the [OK] button.
The document area to be monitored for multifeeds is set.
Multifeed may not be detected for the top and bottom 25mm of a doc-
ument.
z For multifeed detection, a length of at least 5mm is required. Specify
a value for #2 that is at least 6mm greater than that for #1.
z "#2" can have a maximum value of 510mm. If the paper size setting
is long page mode but the length of the document is longer than
510mm, multifeed cannot be detected by length.
z When [Middle] is selected, if the document is shorter than "#1", multi-
feed will not be detected. When [Top & Bottom] is selected, if the
document is shorter than "#2", multifeed will not be detected for the
bottom part.
z If the values specified for "#1" and "#2" exceed the actual paper size,
multifeeds will not be detected.
