82
â– Offset Settings
If the scanned output is found to be displaced relative to the actual documents being scanned, the
scan offsets can be adjusted.
1. On the "Scanner Adjustment" screen, under [Front Side Offsets]/[Reverse Side Off-
sets], enter values for the "Horizontal Offset" and "Vertical Offset" input fields.
Offset lengths are measured in units of 0.5mm and may be set to between -4 (-2mm) and
+4 (+2mm).
2. Press the [OK] button.
 The offset settings are set.
â– Length Magnification Setting
If the scanned output is found to be vertically distorted (stretched or squashed) relative to the actual
documents being scanned, the length magnification can be adjusted.
1. On the "Scanner Adjustment" screen, enter the value for the "Length Magnification"
input field.
This changes the length magnification correction value of the vertical scan. Using the fac-
tory default setting as a starting point, the length of the scan can be magnified or reduced to
between -3.1 and 3.1%.
2. Press the [OK] button.
 The length magnification setting is set.
