484
A.5 Multifeed Detection Conditions
There are three multifeed detection modes: document layer, document length, and both document
layer and length. The following conditions must be satisfied in each of these detection modes.
The type of document and document conditions can cause the multifeed detection rate to drop.
A.5.1 Detection by Layer
If [Ultrasonic] is selected in "6.9.17 Multifeed Detection (Layer and Length)" (page 399), muli-
feeds are detected by layer.
In this case, set sheets of the same thickness in the ADF at any one time.
z Document thickness: 0.065 to 0.15mm
z Punched holes are not allowed within 17.5mm (0.7in) either side of the center of paper.
z Do not glue on any other paper within 17.5mm (0.7in) either side of the center of paper.
A.5.2 Detection by Length
If [Length] is selected in "6.9.17 Multifeed Detection (Layer and Length)" (page 399), multifeeds
are detected by length
In this case, set sheets of the same length in the ADF at any one time.
z Document length deviation: 1% or less
z Punched holes are not allowed within 17.5mm (0.7in) either side of the center of paper.
To Next Page
