fi-6010N Network Scanner Operator's Guide 483

A.4 Area not to be Perforated

ADF feed problems can occur while scanning if the document has any holes (punched, etc) in the

shaded area shown in the following figure.

17.5mm

Page top

Front side

Feed

direction

Page bottom

Center of paper
