7.2 Cleaning the ADF

fi-6010N Network Scanner Operator's Guide 427

7.2.1 Cleaning the ADF

1. Push the ADF release button, then hold both sides of the top cover and lift it open.

CAUTION

Be careful that the top cover does not shut on your

fingers.

  

 

      
