4.7 Using the Network Settings Menus
fi-6010N Network Scanner Operator's Guide 153
4
■ Setting the Link Speed/Duplex Mode
If the network is not communicating properly, even though the network operating status is correct,
change the Link Speed/Duplex Mode settings.
1. Select the [Network Settings] tab on the top menu.
2. Press the [Network Status] tab on the left side menu.
The "Network Status" screen shows the status of the currently operating network connec-
tion.
3. Press the Link Speed/Duplex Mode [List] button.
The Link Speed/Duplex Mode list appears.
4. Change the setting from "Auto-Negotiation" to a fixed Link Speed/Duplex Mode.
5. Press the [OK] button.
The Link Speed/Duplex Mode setting is changed.
z If connection to LDAP server is not possible, try the following steps:
1. Disconnect the LAN cable, and press the [Shutdown] button on the
touch panel to turn the scanner off.
2. Reboot the scanner with the LAN cable disconnected, and enter a
nonduplicate IP address.
3. Re-connect the LAN cable to the scanner.
z If the DHCP server cannot be reached when DHCP is set to [On], the IP
Address is set to "169.254.XXX.YYY" (where XXX and YYY are arbitrary
values between 0 and 255).
To Next Page
