fi-6010N Network Scanner Operator's Guide 481
A
Take the following precautions when scanning plastic cards (for
example ID cards).
z In Scan Settings, set the Multifeed Setup to [None]. For more details
about Multifeed Setup, refer to "6.9.17 Multifeed Detection (Layer
and Length)" (page 399).
z Place one card at a time into the ADF paper chute.
z Cards must be fed through the ADF in portrait mode, as in the fol-
lowing figure.
z Cards should be placed face down in the ADF paper chute.
z Embossed cards should be placed with the raised lettering side
down.
z Cards should be of the following specifications:
ISO7810-compliant, Type ID-1 cards
Width × Length: 2.1 × 3.4 in / 54 × 86 mm
Thickness: 0.03 ±0.003 in / 0.76 ±0.08 mm
Material: PVC (polyvinyl chloride) or PVCA (polyvinyl chloride ace-
tate)
z Cards that are excessively stiff may not be fed smoothly by the ADF.
z Cards that have become dirty from handling should be wiped clean
before scanning.
Back
side
PORTRAIT
LANDSCAPE
