4.6 Using the System Settings Menus
fi-6010N Network Scanner Operator's Guide 57
4
4. Touch the "+" with your fingertip.
Repeat until the test screen appears, with the following "Calibration" dialog box:
The keyboard may also be used on the calibration screen:
z Press the [Home] key to jump straight to the post-calibration test
screen.
z Use the [] [][][] to move the "+" to a different calibration point.
This allows a bad touch to be redone.
z Press the [Esc] key to stop the calibration process and return to the
"Screen Calibration" screen.
z Press the [Enter] key to close the error dialog. (Not normally needed.)
After being touched, the "+" will move to the next calibration posi-
tion. Each time it stops, touch it again.
