Chapter 9 Page no. 1046
JC-TSG-A-015.fm
GE Healthcare Senographe DS
Revision 1 Service Information and Procedures Class A 2385072-16-8EN
Job Card TSG A015 - Lift Movement Troubleshooting
2-3 TROUBLESHOOTING STEERING GUIDE FOR TYPE 3 LIFT SCREW ASSEMBLY
Use the following flow charts (illustration 6 and illustration 7) to isolate the issue causing the Lift move-
ment problems on systems with a Type 3 Lift Screw Assembly.
ILLUSTRATION 6 - LIFT TROUBLESHOOTING ENTRY - TYPE 3 LIFT SCREW ASSEMBLY
Does customer complain about
Error 102/024 or does Error 102/024 repeatly
appear in the error logs?
Perform the lift trouble shooting steps described
in illustration 7,
Troubleshooting Flowchart For
Lift Movement Problems Related to Errors 102/
013 and 102/014 - Type 3 Lift Screw Assembly
on page 1047
Proceed to the Grease Checks in illustration 7,
and follow the flowchart as required.
NOK
Perform Lift Functional Checks.
See
section 3-1, Lift Functional
Checks
on page 1048. After the
checks, return back here.
OK
No
Yes
Replace Brake Motor
(5413527)
See
Job Card D/R A205 -
Lift Motor
on page 1179.
OK
To Next Page
