Job Card TSG A015 - Lift Movement Troubleshooting
Page no. 1047 Chapter 9
JC-TSG-A-015.fm
ILLUSTRATION 7 - TROUBLESHOOTING FLOWCHART FOR LIFT MOVEMENT PROBLEMS RELATED TO
ERRORS 102/013 AND 102/014 - TYPE 3 LIFT SCREW ASSEMBLY
Perform Lift Functional Checks.
See
section 3-1, Lift Functional
Checks
on page 1048.
NOK
Grease Checks
See
section 3-2, Grease
Checks
on page 1048.
Grease Lift Screw
See
section 3-3, Grease Lift
Screw
on page 1049.
NOK
OK
NOK
Lift Gas Spring Checks
See
section 3-4, Lift Gas Spring
Checks
on page 1052.
NOK
Change Lift Gas Spring
See
Job Card D/R A206A - Lift
Gas Spring
on page 1183.
Perform Lift Functional Checks.
See
section 3-1, Lift Functional
Checks
on page 1048.
OK
NOK
Perform Lift Functional Checks.
See
section 3-1, Lift Functional
Checks
on page 1048.
OK
OK
Nut, Bearing, and Lift Checks
See
section 3-5, Bearing and
Lift Checks
on page 1057.
OK
If Nut, Bearing or Lift NOK,
change Type 3 Lift without Mo-
tor (5373048), keeping the mo-
tor from the old lift.
See
Job Card D/R A232 - Lift
Screw Assembly
on page 1255.
NOK
Perform Lift Functional Checks.
See
section 3-1, Lift Functional
Checks
on page 1048.
OK
Check Lift Motor
See
section 3-6, Lift Motor
Checks
on page 1057.
Note: If you have just changed
the Lift motor as instructed
above in illustration 6, the Lift
Motor can be assumed to be
OK, so proceed directly to
changing the Lift Board.
NOK
Change Type 3 Lift Motor
(5413527)
See
Job Card D/R A205 - Lift
Motor
on page 1179.
Perform Lift Functional Checks.
See
section 3-1, Lift Functional
Checks
on page 1048.
OK
NOK
Contact OLC.
Corrective actions
Change Lift Board
See
Job Card D/R A201 - Lift
Board
on page 1161.
NOK
Perform Lift Functional Checks.
See
section 3-1, Lift Functional
Checks
on page 1048.
OK
NOK
OK
