The Web Interface
169
8
Note:
1. To allow network connection, you must also enable network connection to the
controller on the Web interface of the GV-CR420 or GV-GF1921 / 1922.
2. Refer to the table for connecting GV-CR420 and GV-AS Controllers through network.
CR420 V1.0 CR420 V1.01
GV-AS210 / 410 / 810 V1.1 or later
GV-EV48
GV-AS1010 / 1110 / 2110 / 2120 / 4110 / 8110
Not
Supported
MAC Address
GV-AS210 / 810 V1.0
GV-AS100 / 110 / 120 with ASBox / ASNet
Barcode Not Supported
[GF1901 / GF1902 / GF1911 / GF1912 Function] Define the GV-GF1901 / 1902 / 1911 /
1912 connected to the controller.
GV-GF1901 / GF1902: Select the RS-485 checkbox and type the XID Number located
on the back of the reader.
GV-GF1911 / GF1912: Select the RS-485 checkbox only if the GV-GF1911 / 1912 is
connected to the controller through RS-485 connection. If the reader is using network
connection, do not check the RS485 box. Type the XID Number located on the back of
the reader.
Click Submit. If the reader is detected, the Connection Status field will be green.
Note: To connect GV-GF1901 / 1902 / 1911 / 1912 through RS-485 connection, the
firmware versions of GV-AS21 / 41 / 81 series Controller must be before 1.4.1 and the
software versions of GV-ASManager must be before V4.4.3.
