UCM6200 Series User Manual
Table 27: Global Policy ParametersNetwork Settings
Configure how the SIP end device shall obtain the IP address. DHCP or PPPoE
can be selected.
• DHCP
Once selected, users can specify the Host Name (option 12) of the SIP end
device as DHCP client, and Vendor Class ID (option 60) used by the client
and server to exchange vendor class ID information.
• PPPoE
Once selected, users need specify the Account ID, Password and Service
Name for PPPoE.
Define the Layer 3 QoS parameter. This value is used for IP Precedence, Diff-
Serv or MPLS. Valid range is 0-63.
Assign the VLAN Tag of the Layer 2 QoS packets. Valid range is 0 -4095.
Assign the priority value of the Layer 2 QoS packets. Valid range is 0-7.
Configure the IP address or Domain name of the STUN server. Only non-
symmetric NAT routers work with STUN.
Specify how often the phone will send a blank UDP packet to the SIP server to
keep the "ping hole" on the NAT router to open. Valid range is 10-160.
Table 28: Global Policy ParametersCustomization
Screen Resolution
1024 x 600
Check this option if the SIP end device shall use 1024 x 600 resolution for the
LCD screen wallpaper.
• Source
Configure the location where wallpapers are stored.
• File
If "URL" is selected as source, specify the URL of the wallpaper file. If
"Local UCM Server" is selected as source, click to upload wallpaper file to
the UCM6200.
Screen Resolution
800 x 400
Check this option if the SIP end device shall use 800 x 400 resolution for the
LCD screen wallpaper.
• Source
Configure the location where wallpapers are stored.
• File
If "URL" is selected as source, specify the URL of wallpaper file. If "Local
UCM Server" is selected as source, click to upload wallpaper file to UCM.
