P a g e | 346

UCM6200 Series User Manual

Figure 255: Cleaner

Table 119: Cleaner Configuration

Enable CDR Cleaner

Enable the CDR Cleaner function.

Clean Files in External

Device

If enabled the files in external device (USB/SD card) will be atomically cleaned

up as configured.

CDR Clean Time

Enter 0-23 to specify the hour of the day to clean up CDR.

Clean Interval

Enter 1-30 to specify the day of the month to clean up CDR.

Enable File Cleaner

Enter the Voice Records Cleaner function.
