Grandstream Networks UCM6204 User Manual

P a g e | 60
UCM6200 Series User Manual
Table 13: Firewall Rule Settings
Rule Name
Specify the Firewall rule name to identify the firewall rule.
Action
Select the action for the Firewall to perform.
• ACCEPT
• REJECT
• DROP
Type
Select the traffic type.
• IN
If selected, users will need specify the network interface "LAN" or "WAN"
(for UCM6200) for the incoming traffic.
• OUT
Service
Select the service type.
• FTP
• SSH
• Telnet
• TFTP
• HTTP
• LDAP
• Custom
If "Custom" is selected, users will need specify Source (IP and port),
Destination (IP and port) and Protocol (TCP, UDP or Both) for the service.
Please note if the source or the destination field is left blank, it will be used
as "Anywhere".
Save the change and click on "Apply" button. Then submit the configuration by clicking on "Apply Changes" on
the upper right of the web page. The new rule will be listed at the bottom of the page with sequence number,
rule name, action, protocol, type, source, destination and operation. More operations below:
• Click on to edit the rule.
• Click on to delete the rule.
Dynamic Defense
Dynamic defense is supported on the UCM6200 series. It can blacklist hosts dynamically when the LAN mode
is set to "Route" under Web GUISystem SettingsNetwork SettingsBasic Settings page. If enabled, the
traffic coming into the UCM6200 can be monitored, which helps prevent massive connection attempts or brute
force attacks to the device. The blacklist can be created and updated by the UCM6200 firewall, which will then
be displayed in the web page. Please refer to the following table for dynamic defense options on the UCM6200.

Grandstream Networks UCM6204 Specifications

General

Brand	Grandstream Networks
Model	UCM6204
Category	PBX
Language	English
