Direct Outward Dialing (DOD)
The UCM6200 provides Direct Outward Dialing (DOD) which is a service of a local phone company (or local
exchange carrier) that allows subscribers within a company's PBX system to connect to outside lines directly.
Example of how DOD is used:
Company ABC has a SIP trunk. This SIP trunk has 4 DIDs associated to it. The main number of the office is
routed to an auto attendant. The other three numbers are direct lines to specific users of the company. Now
when a user makes an outbound call their caller ID shows up as the main office number. This poses a problem
as the CEO would like their calls to come from their direct line. This can be accomplished by configuring DOD
for the CEO’s extension.
Steps on how to configure DOD on the UCM6200:
1. To setup DOD go to UCM6200 Web GUIExtension/TrunkVoIP Trunks page.
2. Click to access the DOD options for the selected SIP Trunk.
3. Click "Create a new DOD" to begin your DOD setup
4. For "DOD Number" enter one of the numbers (DIDs) from your SIP trunk provider. In the example above
Company ABC received 4 DIDs from their provider. ABC will enter in the number for the CEO's direct line.
5. If extension number need to be appended to the DID number click on “Add Extension”.
6. Select an extension from the "Available Extensions" list. Users have the option of selecting more than one
extension. In this case, Company ABC would select the CEO's extension. After making the selection, click
on the button to move the extension(s) to the "Selected Extensions" list.
Figure 102: DOD extension selection
