P a g e | 30

UCM6200 Series User Manual

INSTALLATION

Before deploying and configuring the UCM6200 series, the device needs to be properly powered up and

connected to network. This section describes detailed information on installation, connection and warranty policy

of the UCM6200 series.

Equipment Packaging

Table 2: UCM6200 Equipment Packaging

Main Case

Yes (1)

Power Adaptor

Yes (1)

Ethernet Cable

Yes (1)

Quick Installation Guide

Yes (1)

GPL License

Yes (1)

Connect Your UCM6200

Connect The UCM6202

Figure 1: UCM6202 Front View
