UCM6200 Series User Manual
SYSTEM SETTINGS
This section explains configurations for system-wide parameters on the UCM6200. System settings are under
“System Settings” tab on UCM6200 Web GUI. System settings include User Management, Network Settings,
Firewall/Security Settings, Change Password, LDAP server, HTTP server, Email settings, Time Settings, NTP
Server, Recordings Storage and Login Timeout settings.
Network Settings
After successfully connecting the UCM6200 to the network for the first time, users could login the Web GUI and
go to System SettingsNetwork Settings to configure the network parameters for the device.
• UCM6200 supports Route/Switch/Dual mode functions.
In this section, all the available network setting options are listed for all models. Select each tab in Web
GUISystem SettingsNetwork Settings page to configure LAN settings, WAN settings, 802.1X and Port
Forwarding.
Basic Settings
Please refer to the following tables for basic network configuration parameters on UCM6202, UCM6204 and
UCM6208 respectively.
Table 6: UCM6200 Network SettingsBasic Settings
Method
Select "Route", "Switch" or "Dual" mode on the network interface of UCM6200. The default
setting is "Route".
• Route
WAN port interface will be used for uplink connection. LAN port interface will be used
to serve as router.
• Switch
WAN port interface will be used for uplink connection. LAN port interface will be used
as bridge for PC connection.
• Dual
Both ports can be used for uplink connection. Users will need assign LAN 1 or LAN 2
as the default interface in option "Default Interface" and configure "Gateway IP" for
this interface.
MTU
Specifies the Maximum Transmission Unit. (By default, its 1500)
