UCM6200 Series User Manual
Disable This Trunk
If checked, the trunk will be disabled.
Note: If a current SIP trunk is disabled, UCM will send UNREGISTER message
(REGISTER message with expires=0) to the SIP provider.
TEL URI
If the trunk has an assigned PSTN telephone number, this field should be set to
"User=Phone". Then a "User=Phone" parameter will be attached to the Request-
Line and TO header in the SIP request to indicate the E.164 number. If set to
"Enable", "Tel:" will be used instead of "SIP:" in the SIP request. The default setting
is disabled.
Caller ID
Configure the Caller ID. This is the number that the trunk will try to use when
making outbound calls. For some providers, it might not be possible to set the
CallerID with this option and this option will be ignored.
When making outgoing calls, the following rules are used to determine which
CallerID will be used if they exist:
• The CallerID configured for the extension will be looked up first.
• If no CallerID is configured for the extension, the CallerID configured for the
trunk will be used.
• If the above two are missing, the "Global Outbound CID" defined in Web
GUIPBX SettingsGeneral Settings will be used.
Need Registration
Select whether the trunk needs to register on the external server or not when
"Register SIP Trunk" type is selected. The default setting is No.
Username
Enter the username to register to the trunk from the provider when "Register SIP
Trunk" type is selected.
Password
Enter the password to register to the trunk from the provider when "Register SIP
Trunk" is selected.
Auth ID
Enter the Authentication ID for "Register SIP Trunk" type.
Auto Record
Enable automatic recording for the calls using this trunk (for SIP trunk only). The
default setting is disabled. The recording files can be accessed under Web
GUICDRRecording Files.
Table 51: SIP Register Trunk Configuration Parameters
Basic Settings
Provider Name
Configure a unique label to identify this trunk when listed in outbound rules,
inbound rules etc.
Host Name
Configure the IP address or URL for the VoIP provider’s server of the trunk.
Transport
Configure the SIP transport protocol to be used in this trunk. The default setting is
"All - UDP Primary".
• UDP Only
• TCP Only
• TLS Only
