UCM6200 Series User Manual
Ethernet Capture
The captured trace can be downloaded for analysis. The instructions or result will be displayed in the Web GUI
output result.
Figure 257: Ethernet Capture
Table 121: Ethernet Capture
Select the network interface to monitor.
Check this box to save the capture files in the SFTP server.
Please make sure the configuration of data synchronization works
before.
Storage to External Device
Check this box to activate storage of the capture either on the
USB or SD Card.
Enter the filter to obtain the specific types of traffic, such as (host,
src, dst, net, proto…).
Click to start the trace.
Click to download the trace if trace is stored locally.
The output result is in .pcap format. Therefore, users could specify the capture filter as used in general network
traffic capture tool (host, src, dst, net, protocol, port, port range) before starting capturing the trace.
