UCM6200 Series User Manual
Auto Record
Enable automatic recording for the calls using this extension. The default setting is
disabled. The recordings can be accessed under Web GUICDRRecording Files.
Skip Trunk Auth
• If set to “yes”, users can skip entering the password when making outbound calls.
• If set to “By Time”, users can skip entering the password when making outbound
calls during the selected time condition.
• If set to “No”, users will be asked to enter the password when making outbound
calls.
Time Condition for
Skip Trunk Auth
If ‘Skip Trunk Auth’ is set to ‘By Time’, select a time condition during which users can
skip entering password when making outbound calls.
Dial Trunk
Password
Configure personal password when making outbound calls via trunk.
Support Hot-
Desking Mode
If enabled, SIP Password will accept only alphabet characters and digits. Auth ID will
be changed to the same as Extension.
Enable LDAP
If enabled, the extension will be added to LDAP Phonebook PBX list.
Enable WebRTC
Support
Enable registration and call from WebRTC.
Music On Hold
Specify which Music On Hold class to suggest to the bridged channel when putting
them on hold.
Call Duration Limit
The maximum duration of call-blocking.
Maximum Call
Duration
The maximum call duration (in seconds). The default value 0 means no limit.
Custom Call-info
for Auto Answer
If enabled, when a call is sent to this extension from UCM, the SIP INVITE message
will contain a Call-info header indicating auto answer.
Table 34: SIP Extension Configuration ParametersSpecific Time
Specific Time
Time Condition
Click to add Time Condition to configure specific time for this extension.
Create New IAX Extension
The UCM6200 supports Inter-Asterisk eXchange (IAX) protocol. IAX is used for transporting VoIP telephony
sessions between servers and terminal devices. IAX is like SIP but also has its own characteristic. For more
information, please refer to RFC 5465.
To manually create new IAX user, go to Web GUIExtension/TrunkExtensions. Click on "Add" and a new
dialog window will show for users which need to make sure first to select the extension type to be IAX Extension
before proceeding to fill in the extension information. The configuration parameters are as follows.
