UCM6200 Series User Manual
LAN (when Method is set to "Route")
Select Disable, Auto or DHCPv6.
Disable: the DHCPv6 server is disabled.
Auto: Stateless address auto configuration using NDP protocol.
DHCPv6: Stateful address auto configuration using DHCPv6 protocol.
Enter DHCP prefix. (Default is 2001:db8:2:2::)
Enter the Prefix length for static settings. Default is 64
Enter the DNS server 1 address for static settings. Default is (2001:4860:4860::8888 )
Enter the DNS server 2 address for static settings. Default is (2001:4860:4860::8844 )
Configure starting IP address assigned by the DHCP prefix and DHCP prefixlen.
Configure the ending IP address assigned by the DHCP Prefix and DHCP prefixlen.
Configure the lease time (in second) of the IP address.
LAN (when Method is set to "Switch")
Select Auto or Static. The default setting is Auto
Enter the IP address for static IP settings.
Enter the Prefix length for static settings. Default is 64
Enter the DNS server 1 address for static settings.
Enter the DNS server 2 address for static settings.
LAN 1 / LAN 2 (when Method is set to "Dual")
Users will need assign the default interface to be LAN 1 (mapped to UCM6200 WAN port)
or LAN 2 (mapped to UCM6200 LAN port) and then configure network settings for LAN
1/LAN 2. The default interface is LAN 2.
Select Auto or Static. The default setting is Auto
Enter the IP address for static IP settings.
Enter the Prefix length for static settings. Default is 64
Enter the DNS server 1 address for static settings.
Enter the DNS server 2 address for static settings.
• Method: Route
When the UCM6200 has, method set to Route in network settings, WAN port interface is used for uplink
connection and LAN port interface is used as a router. Please see a sample diagram below.
