9.2 Using a PC Card
151
The following table lists the items saved by settings (ON) made on the [Text Select] screen.
Item RMS fluctuation graph Voltage fluctuation graph
Normal Item Freq Frequency
−
Urms RMS voltage value RMS voltage value
(Voltage fluctuation)
Upk Voltage waveform peak
−
Irms RMS current value
−
Ipk Current waveform peak
−
Uave Average RMS voltage value
−
Iave Average RMS current value
−
Power Item P Active power
−
S Apparent power
−
Q Reactive power
−
PF Power factor/Displacement power factor
−
KF K factor
−
Uunb Voltage unbalance factor
−
Iunb Current unbalance factor
−
UTHD Total harmonic voltage distortion factor
−
ITHD Total harmonic current distortion factor
−
Harmonics U Harmonic voltage
−
I Harmonic current
−
P Harmonic power
−
angl Harmonic voltage-current phase differ-
ence
−
iU Inter-harmonic voltage
−
iI Inter-harmonic current
−
iUth Total Inter-harmonic voltage distortion
factor
−
iIth Total Inter-harmonic current distortion
factor
−
