2.2 Screen Names and Configurations
25
Displays voltage and current vectors
for channels, depending on how they
are connected.
You can display each order
(1st to 50th
order)
for harmonic analysis as a vec-
tors and simultaneously display the
harmonic (RMS value or phase angle)
and unbalance factors as numerical
values.
For phase angle display, you can se-
lect ±180° display or 360° lag display.
Up to 10th order harmonics can be dis
played when measuring 400 Hz.
Example screen: Displays vectors for
4, 3P4W (three-phase four-wire) chan
nels.
VECTOR 5.3 "Vector Display"(page 70)
Press to switch the display screen.
VECTOR VIEW Screen
