Hisun HS700UTV-4 - Checking the Differential Gear Oil; Changing the Differential Gear Oil

MAINTENANCE AND ADJUSTMENT OF THE UTV
- 111-
Periodic oil change
0.25 L (0.22 Imp qt)
Total amount
0.28 L (0.25 Imp qt)
WARNING :
Take care not to allow foreign material to
enter the final gear case.
·Install:
oil filler plug
23 Nm (2.3 m · kg, 17 ft · lb)
CHECKING THE DIFFERENTIAL GEAR OIL
1. Place the vehicle on a level surface.
2. Remove:
·oil filler plug ①
3. Check:
·oil level
Oil level should be up to the brim of hole.
Oil level low
Add oil to proper level.
WARNING :
Take care not allow foreign material to ente
r
the differential gear case.
4. Install:
·oil filler plug
23 Nm (2.3 m · kg, 17 ft · lb)
CHANGING THE DIFFERENTIAL GEAR OIL
1. Place the vehicle on a level surface.
2. Place a receptacle under the differential gea
r
case.
3. Remove:
·oil filler plug ①
4. Drain:
·differential gear oil
5. Install:
·drain plug
