Hisun HS700UTV-4 - Rear Arm Shaft

CHASSIS
- 279-
Rear arm shaft
No. Part Name Qty Remarks
Removing the rear arm shaft
1 Rear right upper swing arm 1
2 Rear left lower swing arm 1
3 Rear right lower swing arm 1
4 Middle rubber tube, swing arm 8
5 Hexagon flange bolt M10×1.25×70 8
6 Hexagon flange nut M10×1.25 10
7 Rear left upper swing arm 1
8 Dust cover B 16
9 Protective board, rear right lower swing arm 1
10 Protective board, rear left lower swing arm 1
