ENGINE
- 174 -
CRANKCASE STARTER MOTORAND OIL FILTER
No. Part Name Qty Remarks
Remove the starter motor, timing
chain and oil filter
Remove the parts in the order listed.
A.C. magneto rotor
Primary and secondary sheaves
Clutch carrier assembly
1 Starter motor/O-ring 1/1
2 Oil filter cartridge/O-ring 1
3 Oil pipe assembly/O-ring 1/2
4 Oil pipe adapter/O-ring 1/1
5 Relief valve assembly 1
6 Speed sensor 1
7 Shift drum stopper 1
8 Gear position switch 1
