Hisun HS700UTV-4 - Transmission System; Front Axle

CHASSIS
- 245-
TRANSMISSION SYSTEM
Front Axle
No. Part Name Qty Remarks
1 Circlip 1
2 Double off-set joint assembly 2
3 Circlip 2
4 Circlip 2
5 Hoop A, dust P shed Φ80 4
6 Outer rubber dust-P cover (C-1610) 2
7 Hoop B, dust P shed Φ32 4
8 Joint shaft 1
9 Inner rubber dust-p cover (C-1605) 2
10 Front left C.V axle 1
11 Front right C.V axle 1
